Pump Solutions Group Neptune Alternative Power Pumps for Agriculture - Manual (Page 2)

© 2009 Neptune Chemical Pump Company
All Rights Reserved
Bulletin AGP-09 P/N ZL______ Printed in U.S.A.
P.O. Box 247 • Lansdale, PA 19446-0247
Tel: 215-699-8700 • Fax: 215-699-0370
Toll-Free Tel: 1-888-3NEPTUNE (1-888-363-7886)
Toll-Free Fax: 1-800-255-4017
Web Site: http://www.neptune1.com
E-mail: [email protected]
Agricultural Services Center
P.O. Box 406 • 201 S. Georgetown Unit #1 • Yuma, CO 80759
Tel: 970-848-2550 • Fax: 970-848-2652
Features
• Operates from 94 VAC to 264 VAC
• Manual stroke length adjustment
50 to 100%
• Manual and automatic stroke speed
adjustment
• External interlock available
• Repeat cycle and counter functions
built in
Tech
• Manual, 4-20 mA or water pulse
controlled
• Available in PVC, Acrylic and Kynar
• Automatic degassing valve option
Performance
• 0.5 ml per stroke/min.;
1300 ml/min.
Certifications
• CE available in all models
Features
• Self priming
• Superior performance when pumping chemicals
• Accepts NEMA and IEC flange mounts
• Suction lift to 20 ft.
• Manual micrometer stroke length adjustment
Tech
• Automatic capacity control
using variable speed drive
• Liquid ends are available in
PVC, Kynar and 316SS
Performance
• Capacities range from
0.6 gph to 300 gph and
pressures to 150 psi
• Viscosities up to
20,000 cps
Certifications
• CE
Features
• EZE-clean valve cartridges
• Variable oil by-pass stroke adjustment
• NEMA and IEC flange mount available
• Manual micrometer stroke length adjustment
• Bright color contrasted dial protected from corrosion
by clear PVC covering
Tech
• Available in 316SS, PVC, Alloy 20 and Kynar
• Automatic stroke control
length and speed adjustment
• Double diaphragm
available in all models
Performance
• Range 0.02 gph to
240 gph
• Pressures to 4000 psi
Certifications
• CE, API
PZ PUMP
SERIES 7000 SERIES 500
