Serial Communication, cont’d
System 5cccccrrrrr Plus • Serial Communication 4-4
Command/response table for SIS commands
Command description Command Response Additional
ASCII Hex (switcher to host) description
Input selection
Select both video and audio X1 ! 30 + X1 21 C X1 Video & audio input X1 .
Select audio only X1 $ 30 + X1 24 A X1 Audio input X1 .
Select video only X1 & 30 + X1 26 V X1 Video input X1 .
Room function
Turn room function on O 4F Rly X2 On.
Turn room function off o 6F Rly X2 Off.
Display (projector) power
Turn display power on [ 5B Pwr X3 On (discrete).
Turn display power off ] 5D Pwr X3 Off (discrete).
Display mute
Toggle display mute on/off S/s 53/73 Mut Use S or s to toggle mute.
Display mode
Toggle display mode J 4A Mde
Audio gain/attenuation
Increase audio gain {G 7B 47 Aud X4 Increment up (amp output).
Decrease audio gain }G 7D 47 Aud X4 Increment down (amp out.).
Set amp output gain 0* X4 G 30 2A X4 47 Aud X4 Affects master output volume.
Set input attenuation 1* X4 G 31 2A X4 47 Aud X4 Adjusts the active input’s gain.
Read attenuators *A 2A 41 X4 • X4 • X4 • X4 • X4 Displays the attenuation
status for audio inputs PC 1,
PC 2, Input 3, Vid 1, and
Vid 2, in that order.
Video configuration
Set video signal type X5 * X6 \ X5 2A X6 5C Vid/Y-C/RGB Set signal type for Input 3,
Vid 1, or Vid 2.
Firmware version, part number, & information requests
Query firmware version number Q/q 51/71 Ver X7 • X7 Display controller and
IR firmware version.
Request part number N/n 4E/6E N60-269-02 Display switcher’s part #.
Request information Command = I/i 49/69 (see below) Display status.
Response = V X1 •A X1 •T X6 •Pwr X3 •Rly X2 •Clp X2 • Amt X2 •Aud X4
Note : Amt is audio mute.
The command/response tables use symbols (defined below) to represent variables.
X4 = Audio attenuation steps (0 through 100)
X5 = Which configurable video input (3 through 5)
3= Input 3 ....... Input 3 can be composite video,
S-video, or RGB.
4 = Vid 1 .......... Vid 1 can be composite video or
S-video.
5 = Vid 2 .......... Vid 2 can be composite video or
S-video.
X6 = Video input signal type (0 through 2)
0 = RGB
1 = composite video
2 = S-video
X7 = Switcher main controller firmware version
(listed to two decimal places e.g.: x.xx),
followed by IR firmware version
Symbol definitions
= CR/LF (carriage return/line feed) (hex 0D 0A)
• = Space
X1 = Input number (0 through 5)
0 = no connection
1 = PC 1
2 = PC 2
3 = Input 3
4 = Vid 1
5 = Vid 2
X2 = 0 = off, 1 = on
X3 = Display power status (0 through 3)
0 = display power is off
1 = display power is on
2 = display is powering down
3 = display is powering up
