RCP 1000 • Operation
Operation, cont’d
RCP 1000 Remote Control Panel
A
Appendix
Reference Information
Installing a Firmware Update
Specifications
Part Numbers
3-8
1.
Press the preview input button to display the preview
image on the preview monitor.
2.
Press the Effect button that has been programmed for the
title. (If the button is already lit, you do not need to press
it.)
3.
The title effect will either be window or key.
When you want the title to begin, press the Take button. If
the title effect is window, a portion of the program image
dissolves to reveal the preview window. If the title effect is
key, any portion of the preview image which is over half
intensity (.35V) will be displayed with the program image.
The Take light remains on.
4.
When you want to end the title effect, press the Take
button again. The title dissolves during the time specified
by the duration, and the Take button light turns off.
