7.
Modify the border color:
a.
In the Font information section of the TextDialog screen, double-click the
Border
Color
box to change the border (stroke) color. The Select a Color screen opens.
b.
Adjust the color settings as desired.
c.
Click
OK
to accept the border color parameters and return to the TextDialog screen.
Alternatively, click
Cancel
to return to the TextDialog screen without making
changes.
8.
On the TextDialog Screen, click
OK
to return to the
Drawing Settings
tab.
Timecode stamp
To add a timecode stamp:
1.
In the Text section of the
Drawing Settings
), click the
button and
select
Timecode
from the drop-down list of options.
2.
In the Text section, click the
button to add a timecode stamp. A timecode stamp
(00:00:00:00) appears in the upper left corner of the output display.
NOTE: Move the timecode stamp into the output frame (within the red-bordered
image) or it will not appear on the output screen. The text block position
can be anywhere on the output frame.
3.
You can edit the position and appearance of the timecode stamp using the same
procedures as described for text blocks in “
.”
You cannot edit the contents of the timecode stamp. This changes automatically for
each frame during the encoding process.
4.
On the
Drawing Settings
tab, click
OK
to return to the main screen of the
JPEG 2000 Encoder.
Options Menu
The options available on the
Options
menu depend on which version of the application (lite
or full version) is in use.
Threads
NOTE: The
Threads
option is available only with the full version of the software.
This option allows the use of multiple threads (computer processor cores) for increased
system throughput.
To adjust the threads setting:
1.
From the
Options
menu, select
Threads
to access the slider bar.
2.
Click and drag the slider bar to change the threads value. The maximum number is
limited to the number of cores on the computer.
