Effect Settings tab
The features on the
Effect Settings
tab allow you to crop and scale the video for
multi-screen applications or to match the native resolution of the target display device.
NOTES:
•
The available effect options depend on the settings in the encoding parameters
and the incoming frame size (see “
•
The
Effect Settings
tab is disabled if the resolution of the source graphics
file matches the target encoder resolution.
Figure 7.
Effect Settings Tab
Disabled
The
Disabled
option on the
Effect Settings
tab indicates that no effects are in use and
the output display window remains black.
The image description that is displayed for this option includes:
z
Image Size — The horizontal and vertical pixel format of the source frame
z
Target Size — The desired pixel aspect of the output frame
z
Position — 0,0 (default position). No adjustment is possible in this mode.
