Description Part Number
VC 50 Volume control wall plate 70-530-02
VCM 100 AAP Volume/mute - AAP 70-396-11
VCM 100 MAAP Volume/mute - MAAP 70-397-11
VCM 200 D Volume control wall plate 70-883-02
VCM 200 EU Volume control wall plate 70-884-05
VCM 200 MK Volume control wall plate 70-884-03
MLA VC10 Plus Volume control module 60-1090-01
SM 3 compact, full range speakers with SpeedMount ™ (Black, White) 42-133-xx
SI 3CT LP full range ceiling speakers 42-103-03
SI 26 two way surface mount speakers (Black, White) 42-072-xx
SI 26X two way open back ceiling speakers 42-067-03
FF 120T Flat Field ® speakers 42-120-13
FF 220T Flat Field speakers 42-141-03
SPK14/1000 Non-Plenum 1000 feet (300 m) spool 22-152-03
SPK14P/1000 Plenum 1000 feet (300 m) spool 22-155-03
SPK16/1000 Non-Plenum 1000 feet (300 m) spool 22-151-03
SPK16P/1000 Plenum 1000 feet (300 m) spool 22-154-03
SPK18/1000 Non-Plenum 1000 feet (300 m) spool 22-150-03
SPK18P/1000 Plenum 1000 feet (300 m) spool 22-153-03
Mounting
Plenum Placement
The MPA 152 amplifier complies with Section 300.22 (c) of the National Electrical Code and
is suitable for use in an Environmental Air Space. It can be installed in the ceiling, out of
sight, with reduced risk of theft.
ATTENTION: Although the amplifier is plenum rated, the power supply provided with
it is not. The power supply must not be placed in the plenum space. Cables to and
from the amplifier must also be plenum rated.
Tabletop Placement
Attach the four provided rubber feet to the bottom of the unit and place it in any convenient
location.
MPA 152 • Reference Material 13
