37
IN1408 Operation Manual - V1.4 3/21/02 12:32 PM © 2002 - INLINE, Inc.
IN1408 SERIAL COMMANDS
COMMAND DESCRIPTION
ACI3 set baud rate to 1200
ACI4 set baud rate to 2400
ACI5 set baud rate to 4800
ACI6 set baud rate to 9600**
ACI7 set baud rate to 19,200
ACI8 set baud rate to 38,400
ACI9 set baud rate to 57,600
ACI? return baud rate
AL+ increase active lines
AL- decrease active lines
AL@ set active lines to normal**
♦
ALxxx set active lines to absolute
value
♦
AL? return active lines
AP+ increase active pixels
AP- decrease active pixels
AP@ set active pixels to normal**
♦
APxxx set active pixels to absolute
value
♦
AP? return active pixels
ASP0 set aspect ratio to standard**
ASP1 set aspect ratio to
anamorphic
ASP2 set aspect ratio to wide
screen
ASP3 set aspect ratio to wider
screen
ASP4 set aspect ratio to Expand
ASP? return aspect ratio
BALR increase balance right
BALL increase balance left
BAL@ set audio balance to center**
(015)
BALxxx set balance to absolute value
(000-030)
BAL? return balance
BAS+ increase bass
BAS- decrease bass
BAS@ set bass to normal (005)
BASxxx set bass to absolute value
(000-010)
BAS? return bass
BH+ increase horizontal blanking
BH- decrease horizontal blanking
BH@ set horizontal blanking to
normal**
♦
BHxxx set horizontal blanking to
absolute value
♦
BH? return horizontal blanking
BLANK toggle blanking
BLANK0 disable blanking**
BLANK1 enable blanking
BLANK2 set blue screen off
BLANK3 set blue screen on
BLANK? return blank state
BLU+ increase blue RGB gain
BLU- decrease blue RGB gain
BLU@ set blue RGB gain to
normal** (128)
BLUxxx set blue gain to absolute
value (0-255)
BLU? return blue RGB gain
BRG+ increase brightness
BRG- decrease brightness
BRG@ set brightness to normal**
(128)
BRGxxx set brightness to absolute
value (000-255)
BRG? return brightness
BV+ increase vertical blanking
BV- decrease vertical blanking
BV@ set vertical blanking to
normal**
♦
BVxxx set vertical blanking to
absolute value
♦
BV? Return vertical blanking
CH1 select channel 1
CH2 select channel 2
CH3 select channel 3
CH4 select channel 4
CH5 select channel 5
CH6 select channel 6
CH7 select channel 7
CH8 select channel 8
CH? Return channel
CMDCD0 set delimiters to brackets [
]**
CMDCD1 set delimiters to braces { }
CMDCD2 set delimiters to parentheses
( )
CMDCD3 set delimiters to less and
greater < >
CMDCD4 set delimiters to slashes \ /
CMDCD5 set delimiters to signs !#
CMDCD? Return delimiters
