5
© 1996-1997 - INLINE, INC. IN3554 / IN3556 OPERATION MANUAL - REV. 2.1 02/19/00
SPECIFICATIONS
IN3554 / IN3556
RGBHV Switcher
Inputs
Connector type 5 BNC Female
Number of Inputs IN3554: 4 Inputs
IN3556: 6 Inputs
Maximum Signal
Components per Input
5
Signal Compatibility
RGBHV, RGBS, RGsB, RsGsBs, Monochrome with Sync, Composite Video, Y/C,
Component Video, Audio
Output
Connector type 5 BNC Female
Bandwidth 500 MHz @ -3dB
Isolation 60 dB @ 50 MHz 55 dB @ 75 MHz 50 dB @ 100 MHz
Switching Time 3.0 mS
Power
Voltage 110 / 220 - User Selectable
Consumption 10 Watts
Dimensions
Size Height: 4.4" / 11.2cm Width: 8.5" / 21.6cm Depth: 5.1" / 13.0cm
Weight Product Weight: 4 lbs. / 1.8 Kg Shipping Weight: 6 lbs. / 3 Kg
Parts Included AC Power Cable (US Only)
Operation Manual
Optional Accessories
Input / Output Cables IN7000-5 Series Standard Resolution 5-BNC Cables
IN7200-5 Series: Ultra High Resolution 5-BNC Cables
IN7300-5 Series: Super High Resolution, 5-BNC Cables
Available in a variety of lengths from 6’ to 250’. .
Stereo Audio Switcher
IN3546R Stereo Audio Switcher - Featuring 6 Inputs and 1 Output, the IN3546R adds stereo audio -
follow-video capabilities to IN3500 Series Switchers. The IN3546R attaches to the IN3500 Series
REMOTE CONTROL port and receives both power and switching commands from the control port.
Control
IN3590 Wired Remote Control with 25’ Long Cable
Allows Remote Channel Selection for IN3500 Series Switchers
TROUBLESHOOTING
The display device connected to the RGBHV output has a bad/scrambled image.
Solution 1: The display device connected to the output of the switcher may not be compatible with the
computer output. CGA and EGA signals vary from 15.75 to 24 KHz. VGA runs at
31.5 KHz, but SVGA can be as high as 48 - 58 KHz. MACII/Quadra computers sense what
monitor is connected and configure themselves accordingly, with horizontal scan rates
ranging from 24.48 to 68.9 KHz. Graphics workstations may put out frequencies as high as
82 KHz. Check the operations manual on both the computer graphics card and the display
device to ensure that they are compatible.
