IR 101 Universal Remote

IR 201 SYS 4/8/10/AV Remote

68-200-01 Rev. E

Printed in the USA

04 02

Infrared Remote Controls

1

.

Power down the switcher.

2

.

Connect the IR 101 adapter’s 25-pin plug to the Remote
connector on the switcher’s rear panel.

3

.

Plug the IR detector’s RJ-11 male connector into the IR 101
adapter’s rear panel RJ-11 female connector.

4

.

Position the IR detector for the best line of sight of the infrared
light from the IR 101 hand-held remote controller.

5

.

Power up the switcher.

IR 201 (Part #70-141-03) installation

Install the IR 201 Sys 4/8/10/AV remote control system (figure 3) as
follows:

INPUTS

L

R

L

R

L

R

L

R

L

R

L

R

1

2

3

4

5

6

L

R

A

B

L

R

OUTPUTS

SW 6 SA MX

IR-201 remote control adapter

IR-201 remote control

RS-232

T-connector

3 foot cable

6 foot
cable

IR detector

IR-201

RS-232

control

Power

supply

Figure 3 — Typical IR 201 application

1

.

Power down the switcher.

2

.

Connect the IR 201 adapter’s 9-pin T-connector to the RS-232
connector on the switcher’s rear panel. If desired, connect a
host device, such as a computer or touch panel control, to the
switcher via this 9-pin D connector for serial RS-232 control.

3

.

Plug the IR detector’s RJ-11 male connector into the IR 201
adapter’s rear panel RJ-11 female connector.

4

.

Connect the external power supply to the IR 201 adapter. Plug a
standard IEC power cord into the power supply to connect the
adapter to a 100 to 250VAC, 50 Hz or 60 Hz power source.

5

.

Position the IR detector for the best line of sight of the infrared
light from the IR 201 hand-held remote controller.

6

.

Power up the switcher.
