DVI-RGB 150 • Reference Information
Reference Information
DVI-RGB 150 • Reference Information
A-2
A-3
Specifi cations
Video
N
The DVI-RGB 150 converts a single link DVI signal to an
analog RGB signal.
N
Using an adaptor (the Extron HDMI to DVI-D adapter, part
#26-616-01), the DVI-RGB 150 can accept HDMI signals. It
converts HDMI digital RGB signals, but does not support the
HDMI digital component (YCrCb) signal format.
Video input and loop-through
Number/signal type ..................... 1 single link DVI-D digital video input
1 single link DVI-D buffered loop-through
Connectors .................................... 1 DVI-D female (DVI input)
1 DVI-D female (DVI loop through)
TMDS nominal level ..................... 0.4 V to 0.6 V swing
TMDS impedance ......................... 100 ohms
DC offset (max. allowable)........... ±0.5 V
Video output
Number/signal type ..................... 1 RGBHV, RGBS, RGsB
Connectors .................................... 6 BNC female
Nominal level ................................ 0.7 Vp-p for RGB
Level adjustment range ................ 0 dB to 6 dB (x1 to x2)
Peaking adjustment range ........... 0 dB to 6 dB (x1 to x2) at 100 MHz
Impedance ..................................... 75 ohms
Output resolution .......................... Follows input, determined by the local
DVI loop-through monitor or by the
selector on this product.
Resolution selector resolutions and rates
Setting Resolution Refresh Low Refresh High
0
640x480
60
Hz
75
Hz
1
800x600
60 Hz
75 Hz
2
852x480
60 Hz
75 Hz
3
1024x768
60 Hz
75 Hz
4
1024x852
60 Hz
75 Hz
5
1280x768
60 Hz
75 Hz
6
1280x1024
60 Hz
75 Hz
7 1365x768 60
Hz
75
Hz
8
1366x768
60 Hz
75 Hz
9
1400x1050
60 Hz
60 Hz
A
1600x1200
60 Hz
60 Hz
B
480p
60
Hz
60
Hz
C
576p
50
Hz
50
Hz
D
720p
50
Hz
60
Hz
E
1080i
50
Hz
60
Hz
F
1080p
50
Hz
60
Hz
Return loss ..................................... -35 dB @ 5 MHz
DC offset ........................................ ±5 mV maximum with input at 0 offset
Output cable driving distance ..... 150’ (45 m) at 1600 x 1200 with Extron
MHR cable
250’ (60 m) at 1024 x 768 with Extron MHR
cable
Sync
Output type .................................... RGBHV, RGBS, RGsB
Output level ................................... TTL (5 Vp-p, unterminated)
Output impedance ........................ 75 ohms
Polarity............................................ Positive or negative (follows input)
