DTP DVI 230 Tx/Rx Transmitter and Receiver • Reference Information
10
Reference
Information
This section provides procedures for mounting the DTP DVI 230 Tx/Rx transmitter and
receiver and disconnecting the ground between them.
•
Mounting the Transmitter or Receiver
•
Mounting the Transmitter or Receiver
ATTENTION:
•
Installation and service must be performed by authorized personnel only.
•
Avoid ground potential differences between the transmitter and receiver installation
sites, which can lead to
equipment damage or a missing or unstable picture. If
a potential difference cannot be avoided, remove the ground connection between
the units and locally power both units (see
next page).
The 1‑inch high, quarter rack width DTP DVI 230 transmitter or receiver can be placed on
a table, mounted in a rack, or mounted under a desk or table. The receiver can also be
mounted on a projector bracket.
Tabletop Use
Affix the included rubber feet to the bottom of the unit and place it in any convenient
location.
Mounting kits
Mount the unit using any optional compatible mounting kit listed on the Extron website
(
www.extron.com
), in accordance with the directions included with the kit. For rack
