Specifications (Cont’d) Specifications
CVC 200 • Specifications 5 CVC 200 • Specifications 6
Specifications
Video
Gain ................................................ Unity
Bandwidth ..................................... 55 MHz (-3 dB)
Video input
Number/signal type ..................... 1 component video [HDTV, W-VHS (Y, P r , P b ),
SMPTE (Y, R-Y, B-Y), and Betacam ®
(Y, R-Y, B-Y)] or RGsB
Connectors .................................... 3 BNC female
Nominal level ................................ 1V p-p for Y of component video
0.3V p-p for R-Y and B-Y of component video
0.7V p-p for P
B
P
R
Minimum/maximum levels ........ Y: 0.5 V to 1.5 Vp-p with no offset at unity gain
P
B
P
R
: 0.4 V to 1.0 Vp-p with no offset at unity
gain
Impedance ..................................... 75 ohms
Horizontal frequency .................... 15.75 kHz to 100 kHz according to selected mode
Vertical frequency .......................... 60 Hz
Return loss ..................................... <-25 dB @ 5 MHz
DC offset (max. allowable)........... ±2 V (maximum)
Video output
Number/signal type ..................... 1 RGBHV, RGBS
Connectors .................................... 6 BNC female
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ RGB: 0.4 V to 1.0 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-30 dB @ 5 MHz
DC offset ........................................ 0.1 V with input at 0 offset
General
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 12 watts,
internal, autoswitchable
Temperature/humidity ................ Storage -40° to +158°F (-40° to +70°C) / 10% to
90%, noncondensing
Operating +32° to +122°F (0° to +50°C) / 10% to
90%, noncondensing
Rack mount .................................... Yes, with optional rack shelf,
part #60-190-01 or #60-604-01
Enclosure type .............................. Metal
Enclosure dimensions .................. 1.6” H x 8.75” W x 9.4” D
(1U high, half rack wide)
4.1 cm H x 22.2 cm W x 23.9 cm D
(Depth excludes connectors.)
Product weight .............................. 2.8 lbs (1.3 kg)
Shipping weight ........................... 5 lbs (3 kg)
Vibration ........................................ ISTA 1A in carton
(International Safe Transit Association)
Listings............................................ UL, CUL
Compliances ................................... CE
MTBF ............................................... 30,000 hours
Warranty ........................................ 3 years parts and labor
N All nominal levels are at ±10%.
N Specifications are subject to change without notice.
