Bell & Gossett P71397B Series 80-SC Spacer-Coupled Vertical In-Line Centrifugal Pump Motor Collar Ring User Manual
Page 2
MOTOR
MOUNTING
SURFACE
COLLAR
RING
DC
FIG. 1
TC MOTOR
FIG. 2
IEC MOTOR
MOTOR
MOUNTING
SURFACE
COLLAR
RING
DC
Xylem Inc.
8200 N. Austin Avenue
Morton Grove, Illinois 60053
Phone: (847) 966-3700
Fax: (847) 965-8379
www.xyleminc.com/brands/bellgossett
Bell & Gossett is a trademark of Xylem Inc. or one of its subsidiaries.
© 2013 Xylem Inc. P71397B February 2013
