WARNING: - Electrical Grounding Hazard - Adequate electrical grounding is required for

the safe operation of Laing Pumps. Ground the pump back to the service using a copper

conductor at least the size of the circuit connectors supplying the pump. Connect the ground

wire to the ground terminal in the wiring compartment. Failure to follow these instructions

could result in serious personal injury, death and/or property damage.

WARNING: - Risk of Electric Shock - Do not install this pump in swimming pool or marine

areas. Failure to follow these instructions could result in serious personal injury, death and/or

property damage.

WARNING: - Electrical Shock Hazard - Disconnect and lockout the power before

servicing. Failure to follow these instructions could result in serious personal injury, death

and/or property damage.

Removal of Pump From Existing System For Replacement

WARNING: - Electrical Shock Hazard - Electrical connections are to be made by a qualified

electrician in accordance with all applicable codes, ordinances and good practices. Failure

to follow these instructions could result in serious personal injury, death and/or property

damage.

Electrical Safety

WARNING: - Hot Water Hazard - Before draining the system, allow water to cool to at least

100F, open the drain valve (take precautions against water damage) and leave the drain valve

open until servicing is complete. Failure to follow these instructions could result in serious

personal injury, death and/or property damage.

WARNING: - Electrical Shock Hazard - Be certain the electrical power is not present at the

motor leads before continuing. Failure to follow these instructions could result in serious

personal injury, death and/or property damage.

WARNING: - High Pressure Hazard - Pressure may be present in the pump body. This

pressure can be relieved by loosening the flange bolts and shifting the pump assembly

slightly to allow the pressurized water to escape. Failure to follow these instructions could

result in serious personal injury and death.

1. Close the valves on the suction and discharge sides of the pump. (if no valves have been installed, it

may be necessary to drain the system.)

2. Disconnect the electrical supply lines to the pump.
