13
Configuration
Next step is to configure the Connect ® based on the shown signal list. In the
function menu, choose Pump Control 1 and setup the specific menu items as
described in the signal list.
Go to Functions Menu and choose Pump Control 1, which contains the fol-
lowing items:
•
Number of Pumps: Number of pumps in the wasterwater pump station.
• Measurement: The analog input on which the level transmitter is mounted
on and scaling and signal name.
• Pumps Setup
• Start/Stop levels: start and stop levels for current number of pumps.
• Control Word: 16-bit control word for intelligent pump controlling.
• Additional Functions with:
• Flow calculation
• Setpoint displacement
• Depth pumping
• Create Overview Screen: Connect will setup the screen 1 with the entered
information on overview screen 1.
