8
Mounting
GB pHix Compact Manual 100318
Mounting the electrode
Upon delivery of pHix Compact
® , the elec-
trode is not mounted.
pHix Compact
® is configured for the
electrode type included in the delivery, and
therefore it must only be used together with
the electrode with which is was delivered.
pHix Compact ® shoud be used only with
the electrode type included the delivery.
Contact MJK if other electrode types should
be used.
Replacement of the electrode to another of
same type does not require reconfiguration.
The electrode must not become dry.
Therefore, do not remove the protective
cap before before commissioning of pHix
Compact ® .
Gasket, O-ring and plug
It is very important that both gasket and
O-ring and packing surfaces is clean and
smooth and without cracks and scratches
to avoid penetration of liquid in the center
plug connection.
Check that gasket and O-ring are complete and
clean ant that they are placed correctly.
Likewise, the connectors in both transmitter
and electrode should be absolutely clean
and dry. Eventually use a dry cloth.
Check that the connectors are
absolutely clean and dry.
