Xylem PHIX COMPACT pH and Redox Transmitter - Manual (Page 22)

22
Spares and Specifications
GB pHix Compact Manual 100318
Item no: Description:
160310
pHix ® pH electrode, 0-point=4,6 pH
160311 pHix ® pH electrode, 0-point=7,0 pH
160312 pHix ® redox electrode
570054 O-ring for electrode
571030 Black rubber gasket for electrode
521409 Union ring w. Viton gasket
for mounting of pHix on pipe end
521441 Viton gasket for union ring
The followin is recommended for cleaning
and buffer adjustment:
Item no: Description:
163020
Pepsin solution, 0,25l
163030 pH buffer, 6 x 25ml ampoules.
(2 pcs. pH 4, pH 7 and pH 10.)
163032 pH buffer, 1 liter pH 4
163034 pH buffer, 1 liter pH 7
163036 pH buffer, 1 liter pH 10
163040 Redox buffer, 6x25ml;
+230 mV Pt-Ag/AgCl
Spares Specifications
Dimensions
pHix ® Compact
Supply voltage 12-30 V DC
Consumption App. 50mW
Temperature range -20 … +60 °C
Housing material
Ryton (PPS) and
stainless steel
(EN 1.4404 / ASTM 316L)
Enclosure IP 68, withstands
submersion to 10 mWG
Input 0-14 pH/-1000 ... +1000 mV
Input impedance Measuring input: > 10 12 ohm
Reference input: > 10 6 ohm
Output 0-14 pH / 4-20 mA
Temperature comp. -20 … +80 °C
Temp. electrode
Built-in behind steel section.
Buffer adjustment Automatic with tilt switch,
switch ring or HART ®
command
Cable length 6 meter
CE approvals EN50081-1, EN50082-1
Dimensions
NB! Union ring must be orde-
red separately..
1¼" RG
(ISO 228-1)
