e. Set DIP Switches 6-8 to place the decimal point in the correct position
according to the following table:
Decimal Location SW6 SW7 SW8
9999 Off Off Off
9.999 On Off Off
99.99 Off On Off
999.9 Off Off On
f. Set up the sensor for its minimum output current or put the current
loop meter in “Simulate” mode and set it for the minimum output
current of the sensor that will be connected to the EZ100 (4.000mA,
3.986mA, etc). If using a current loop meter, connect the red lead to
terminal S1 and the black lead to terminal S2 according to Figure 1 on
page 5.
g. While holding down the “Display” button on the front panel of the
meter, adjust R3 until the display reads the correct minimum reading.
h. Set up the sensor for its maximum output current or set the current
loop meter for the output current of the sensor that will be connected to
the EZ100 (19.000mA, 19.064mA, 20.000mA, etc).
i. While holding down the “Display” button, adjust R7 until the display
reads the correct maximum reading.
j. Repeat steps f - i and confirm the display reads the correct low and
high values. Readjust R3 and R7 as necessary until the correct
display is achieved without adjustment.
