SDI-12 Command and Response Protocol 3-15
3.15 Extended Read/Write AutoScan Command
When the Module Mode =1 (initiate), the H-4161 actively initiates measurements and collects the
response from the sensor attached to the auxSDI port. These two commands allow the user to
select which “M” command is sent by the H-4161 when it initiates a measurement ( “0M!”,
“0M1!”, “0M2!" etc.) . The H-4161 comes from the factory with this setting set to “0" (“0M!”).
Only the settings “0" to “9" are valid:
0 = 0M! (default)
1 = 0M1!
2 = 0M2!
3 = 0M3!
4 = 0M4!
5 = 0M5!
6 = 0M6!
7 = 0M7!
8 = 0M8!
9 = 0M9!
This setting stored in non-volatile Flash memory. Once a new value is written to the Flash
memory, a copy is sent to the sensor data buffer for verification. This setting can be viewed by
using a subsequent "D" command. To verify this setting any other time, use the "XRMC"
command. This command takes 1 second to complete and places 1 value in the data buffer.
Command Response Description
"aXRAC!" “a0011" Read current AutoScan command setting
"aXWACn!" “a0011" Write current AutoScan command setting
Where: a is the sensor address ("0-9", "A-Z", "a-z", "*", "?").
XRAC are upper case characters.
XWAC are upper case characters.
n is the new parameter
Example of a H-4161 Extended Read Monitored Command command:
Command Response Time Values Description
"aXRAC!" "a0011" 1 sec 1 Read AutoScan setting
Command Response Description
"aD0!" "a+0" Command will be “0M!”
Example of a H-4161 Extended Write Monitored Command command:
Command Response Time Values Description
"aXWAC2!" "a0011" 1 sec 1 Write AutoScan setting
Command Response Description
"aD0!" "a+2" Command will be “0M2!”
