Xylem IM180 R3 Standard and Dual Voltage Motors User Manual
Page 9
CentriPro Motors Installation, Operation and Maintenance Manual
7
Table 1 — 6" Single Phase Motors and Required Control Boxes
Motor HP kW Volts Motor Dia.
Rated Input
Service Factor
L.R. Control Box
Order No.
vs Flange Dia. S.F. Amps Watts Amps Watts Amps Order
No.
6M051
5
3.7
24
4987
27.5
5735
124
CB05MC
6M071 7.5 5.5
230
6" x 6"
1.15
36 7675 41 8950 167 CB07MC
6M101 10 7.5
50
10135
58
11830 202
CB10MC
6M151 15 11
72
15180
85
18050 275
CB15MC
Table 2 — 6" Single Phase Resistance, KVA, Efficiency
Motor HP kW Volts Phase F.L. KVA
Resistance - Ohms
Order No.
Efficiency % Code
R -Y
B - Y
R- B
6M051
5
3.7
74.8
G
2.172 0.512 2.627
6M071 7.5 5.5 230 1
72.9
F 1.401 0.400 1.774
6M101 10 7.5
73.6
E
1.052 0.316 1.310
6M151 15 11
73.7
D
0.678 0.230 0.850
Dow Corning 732-3 or
comparable silicone sealant
Figure 2
Motor Outer side
Voltage Numeral
(460V or 230V)
Top
Bottom
460V
Figure 3
Allen Screws
Pull up straight
Screwdriver
Socket in the
motor housing
VOLTAGE PLUG
Figure 1
Operation (continued)
