Xylem IM180 R3 Standard and Dual Voltage Motors User Manual
Page 25

CentriPro Motors Installation, Operation and Maintenance Manual
23
Motores de CentriPro Instrucciones de instalación, operación y mantenimiento
Dow Corning 732-3 or
comparable silicone sealant
Figura 2
Lado exterior
del motor
Número del voltaje
(460V o 230V)
Parte superior
Parte inferior
460V
Figura 3
tornillos Allen
Tire derecho y
hacia arriba
Destornillador
Tomacorriente
en el cárter
del motor
CLAVIJA DE CONEXIÓN DE VOLTAJE
Figura 1
Operación (continuado)
Tabla 1 — Motores monofásicos de 6" y cajas de control requeridas
No. de
Volt- Diámetro del
Entrada nominal Factor de servicio Amps No. de pedido
pedido del HP kW ios motor v. d. S.F. Amps Watts Amps Watts L.R.
de caja
motor
de la brida
de control
6M051
5
3.7
24
4987
27.5
5735
124
CB05MC
6M071 7.5 5.5
230
6" x 6"
1.15
36 7675 41 8950
167 CB07MC
6M101
10
7.5
50 10135 58 11830
202 CB10MC
6M151
15
11
72 15180 85 18050
275 CB15MC
Tabla 2 — Resistencia monofásica de 6", KVA, rendimiento
No. de
% de
Código
Resistencia – Ohms
pedido del
HP kW Voltios Fase rendimiento F.L. KVA
R -Y
B - Y
R- B
motor
6M051
5
3.7
74.8
G
2.172
0.512
2.627
6M071
7.5
5.5
230 1
72.9
F 1.401 0.400 1.774
6M101
10
7.5
73.6
E
1.052
0.316
1.310
6M151
15
11
73.7
D
0.678
0.230
0.850
