Bell & Gossett DN0130D Domestic Pump 250°F Condensate Units Series SA-PT User Manual
Domestic, Pump 250˚f condensate units series sa, And sa-p
INSTRUCTION MANUAL
DN0130
REVISION D
Domestic
®
Pump
250˚F Condensate Units
Series SA
™
and SA-P
™
SAFETY
INSTRUCTIONS
This safety alert symbol will be used in this manual and on
the unit safety instruction decals to draw attention to safetyÊ
related instructions. When used, the safety alert symbol meansÊ
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!Ê
FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULTÊ
IN A SAFETY HAZARD.Ê
If the decals are missing or are illegible contact your local B&GÊ
representative for a replacement.Ê
1. Electrical connections to be made by a qualified ElectricianÊ
in accordance with all National, State and Local codes.Ê
2. Motor must have properly sized starter with properly sizedÊ
heaters to provide overload and undervoltage protection.Ê
3. If pump, motor or piping are operating at extremely high orÊ
low temperatures, guarding or insulation is required.Ê
4. Operating personnel should be trained in the operation ofÊ
condensate return units.Ê
CAUTION
DO NOT RUN PUMP DRY,
SEAL DAMAGE MAY OCCUR.
INSPECT PUMP SEAL
REGULARLY FOR LEAKS,
REPLACE AS REQUIRED.
FOR LUBRICATION
REQUIREMENTS, CONSULT
SERVICE INSTRUCTIONS.
FAILURE TO FOLLOW
INSTRUCTIONS COULD
RESULT IN INJURY OR
PROPERTY DAMAGE.
P70644
Morton Grove, Illinois 60053
TMÊ
TMÊ
SERIESÊ
MODELÊ
SERIALÊ
GPM
PSI
PUMPÊ
CFM
IN HG.
PUMPÊ
DWGSÊ
POWER V.
PH.
HZ60Ê
CONTROL V.
PH. 1
HZ60Ê
TOTAL
LARGEST MOTORÊ
F.L. AMP
F.L. AMPÊ
DN0016
Morton Grove, Illinois 60053
TMÊ
SERIESÊ
MODELÊ
SERIALÊ
GPM
PSI
PUMPÊ
POWER V.
PH.
HZ60Ê
CONTROL V.
PH. 1
HZ60Ê
TOTAL
LARGEST MOTORÊ
F.L. AMP
F.L. AMPÊ
DOMESTIC
®
PUMPS
WARNING
DO NOT EXCEED PRESSURE
RATING OF THE UNIT.
DO NOT ALTER OR DEFEAT
PRESSURE RELIEF VALVE.
OPEN VALVES SLOWLY.
MAXIMUM PRESSURE 15 PSI.
FAILURE TO FOLLOW
INSTRUCTIONS COULD
RESULT IN INJURY OR
PROPERTY DAMAGE.
DN0124
EXPLOSIBLE
INSTALLER:
PLEASE LEAVE THIS MANUAL FOR THE OWNER’S USE.
SERIES SA-P
™
SERIES SA
™
DN0124 ALL UNITS
DN0016 UNITS PANEL
P70644 ALL UNITS
DN0019 UNITS LESS PANEL
