2
Definitions
Indicates the presences of a hazard
which can cause severe personal
injury, death or substantial property
damage if the warning is ignored.
Indicates the presences of a haz-
ard which will or can cause severe
personal injury, death or substantial
property damage if the warning is
ignored.
Indicates special instructions on
installation, operation or mainte-
nance which is important but not
related to personal injury hazards.
Very Important Safety Information
Always follow these rules to avoid bodily injury or
property damage.
To reduce risk of electric shock, con-
nect only to a properly-grounded
electrical circuit.
Risk of electric shock — this pump
has not been investigated for use in
swimming pool areas.
Before installing or servicing a
pump, check to see that the power
source is disconnected to avoid any
possible electrical shock hazard.
Also, make sure the electrical sup-
ply agrees with the motor wiring
and that the circuit is properly
grounded before operation.
Conformance with local and state
electrical codes is mandatory. If you
are ever in doubt, call a licensed
electrician or your local power com-
pany.
Dual-voltage models are factory
pre-wired for 115 volt operation
on 1/2 and 3/4 hp models and 230
volt on 1 and 1-1/2 hp models. For
all electrical connections, a separate
line with fused switch should be run
from the meter or breaker box and
properly grounded.
TABLE A: RECOMMENDED WIRE AND FUSE SIZES
Name-
plate
HP
Rated
VAC
Branch
Fuse
Amps
Wire Size Chart Distance in Feet – Meter to Motor
0-50 ft.
51-100 ft.
101-200 ft.
201-300 ft.
301-400 ft.
401-500 ft.
1/2
115
15
14
14
10
8
8
8
230
15
14
14
14
14
14
12
3/4
115
15
14
14
10
8
8
8
230
15
14
14
14
14
14
12
1
115
20
12
12
8
6
6
6
230
15
14
14
14
12
12
10
1-1/2
115
20
10
10
8
6
4
4
230
15
14
14
14
12
10
10
Note: Conversion instructions for dual voltage (115/230 volts) can be found on the
wiring diagram instructions on the motor nameplate.
WARNING
CAUTION
NOTICE
WARNING
WARNING
NOTICE
CAUTION
WARNING
