EN-9
CONNECTOR PIN ASSIGNMENT
24-Pin Color Display Signal Cable*
PIN Meaning PIN Meaning
1. TMDS Data2- 13.
2. TMDS Data2+ 14. +5V Power
3. TMDS Data 2/4 Shield 15.
4. 16. Hot Plug Detect
5. 17. TMDS Data0-
TMDS Data0+ 6. SCL
SDA
18.
7. 19. TMDS Data 0/5 Shield
8. NC 20.
9. TMDS Data1- 21.
10. TMDS Data1+ 22. TMDS Clock Shield
11. TMDS Data 1/3 Shield 23. TMDS Clock+
12. 24. DDC TMDS Clock-
* only for certain models
GND
TMDS Data 4-
4+ TMDS Data
TMDS Data3-
TMDS Data 3+
TMDS Data -
TMDS Data +
5
5
