Acer Aspire 4720G - Manual (Page 38)

20
English
Base view
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Hard disk bay Houses the computer's hard disk (secured with
screws).
4 Memory compartment Houses the computer's main memory.
5 Battery release latch Releases the battery for removal.
6 Ventilation slots and
cooling fan Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening of
the fan.
