Acer AOP531h - Manual (Page 12)

12
Series
Specifications
Item Description
Operating system Genuine Windows ® XP Home (Service Pack 3)
Platform Intel ® Atom ™ processor N270 (512 KB L2 cache, 1.60
GHz, 533 MHz FSB) or higher
Mobile Intel ® 945GSE Express Chipset
Mobile Intel ® 82801GBM Chipset
Acer InviLink ™ 802.11b/g
System memory Single channel with one soDIMM slot
• DDR2 533/667 MHz SDRAM memory interface
design
• soDIMM slot: Supports 512 MB / 1 GB
soDIMMs for total system memory of up to 1 GB
Display 10.1" WSVGA high-brightness (typical 200-nit) Acer
CrystalBrite ™ TFT LCD, 1024 x 600 pixel resolution
Storage 2.5" 9.5 mm 160 GB or larger hard disk drive (for
HDD model)
16 GB Solid State Disk (SSD) NAND flash module SD
™
Card reader (for SSD model)
Multi-in-1 card reader
Audio High-definition audio support
Two built-in stereo speakers
MS-Sound compatible
Built-in digital microphone
Communication Integrated Acer Crystal Eye webcam, supporting
enhanced Acer PrimaLite™ technology
WLAN: Acer InviLink
™ 802.11b/g Wi-Fi CERTIFIED ®
network connection, supporting Acer SignalUp ™
wireless technology
LAN: 10/100 Mbps Fast Ethernet
WPAN: Bluetooth
® 2.0+EDR
WWAN: UMTS/HSPA at 850/1900/2100 MHz and
quad-band GSM/GPRS/EDGE (850/900/1800/1900 MHz)(for 3G
models with the Gobi™1000 module)
Communication WWAN: UMTS/HSPA at
850MHz/900MHz/1900MHz/2100 MHz and quad-
band GSM/GPRS/EDGE (850/900/1800/1900 MHz)(for 3G models
with the GTM382E module)
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and
weight
259.41 (W) x 186.8/206.37 (D) x 26.1/33.09 (H) mm
(10.21 x 7.35/8.12 x 1.03/1.3 inches)
1.12 kg (2.48 lbs.)(for HDD model), 1.03 kg (2.26 lbs.)
(for SSD model) for SKUs with 3-cell battery pack
1.27 kg (2.8 lbs.)(for HDD model), 1.17 kg (2.59 lbs.)
(for SSD model) for SKUs with 6-cell battery pack
Power 24.4 W 2200 mAh 3-cell Li-ion battery pack
• 3-hour battery life
57.7 W 5200 mAh 6-cell Li-ion battery pack
• 7.5-hour battery life
30 W adapter with power cord
ENERGY STAR ® 4.0
Input devices 84-/85-/88-key keyboard, 89% standard-size
keyboard with 1.6 mm (minimum) key travel
Multi-gesture touchpad pointing device with two
buttons
I/O Multi-in-1 card reader
Three USB 2.0 ports
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Environment Temperature:
Operating: 5 °C to 35 °C
Non-operating: -20 °C to 65 °C
Humidity (non-condensing):
Operating: 20% to 80%
Non-operating: 20% to 80%
Note: The specifications listed above are for reference only. The exact configuration of your
PC depends on the model purchased.
