Quick Guide
11
Right view
# Icon Item Description
8 Multi-in-one card
reader
Accepts Secure Digital (SD), MultiMediaCard
(MMC), Memory Stick (MS), Memory Stick
PRO (MS PRO), xD-Picture Card (xD).
Note: Push to remove/install the card. Only
one card can operate at any given time.
9 USB 2.0 port Connects to USB 2.0 devices (e.g., USB
mouse).
10 SD Expansion slot Accepts Secure Digital (SD) Card.
Note: Push to remove/install the card.
(only for certain models)
11 DC-in jack Connects to an AC adapter.
12 Kensington lock slot Connects to a Kensington-compatible
computer security lock.
Rear & Base view
13 Battery bay Houses the computer's battery pack.
Note: The battery shown is for reference
only. Your PC may have a different battery,
depending on the model purchased.
14 Battery lock Locks the battery in position.
15 Hard disk bay Houses the computer's hard disk (secured
with screws). (only for certain models)
16 Memory compartment Houses the computer's main memory.
17 Ventilation slots and/
or cooling fan
Enables the computer to stay cool, even
after prolonged use.
Note: Do not cover or obstruct the opening
of the fan.
18 Battery release latch Releases the battery for removal.
19 3G SIM card slot Accepts a 3G SIM card for 3G connectivity.
(only for certain models)
