System tour 2
English
Note: The specifications listed above are for reference only. The
exact configuration of your PC depends on the model purchased.
The table below indicates the functions of the audio jacks on the rear panel
(selected models only):
Environment
Recovery button Network / hard disk drive
indicators
USB 3.0 USB 3.0 ports (selected
models only) Kensington lock slot
DP Display port (selected
models only)
The Display port adapter
is availble on "DP1" only.
DC-in jack (selected
models only)
DVI DVI port (for selected
models only)
Color/use Headphone Stereo Quadraphonic 5.1 CH
Blue
Rear Rear
Green
Headphone Front Front Front
Pink
Mic-in Mic-in Mic-in Center/
woofer
•
Temperature:
•
Operating: 5 °C to 35 °C
•
Non-operating: -20 °C to 65 °C
• Humidity (non-condensing):
•
Operating: 20% to 80%
• Non-operating: 20% to 80%
Icon Description Icon Description
