MU16 / MU26 User Manual
Frequency Chart
Channel Frequency (MHz) Channel Frequency (MHz)
1 863.35 9 864.25
2 863.45 10 864.35
3 863.55 11 864.45
4 863.65 12 864.55
5 863.75 13 864.65
6 863.85 14 864.75
7 863.95 15 864.85
8 864.15 16 864.95
Troubleshooting
No backlight on UHF receiver display
Ensure power adapter is connected to mains and working properly
Ensure receiver is powered on
Receiver display is lit but no level on
“RF” or “AF” meters
Ensure transmitter is switched on
Check that transmitter is not out of reception range
Try IR frequency sync-ing to ensure frequency of transmitter is
same as receiver
Check that transmitter batteries are good / charged
“ “RF” meter is showing good level but
no “AF” and no sound
Check if transmitter switch is in “MUTE” position
Check if neckband or lavalier microphone is connected to beltpack
Ensure transmitter has good / charged batteries
Check if there is another nearby transmitter with the same
frequency – if so, switch frequencies
“RF” and “AF” meters showing good
levels but no sound
Make sure receiver is connected to mixer / amplifier
Make sure that receiver and amplifier / mixer channel volumes are
turned up
Cannot Sync frequencies via IR SYNC.
Place IR Sensor closer to IR Sender
Make sure the correct channel frequency value is flashing on UHF
receiver unit
Microphone output is very loud or
distorted
Turn down GAIN ADJUST on beltpack transmitter
Turn down VOLUME on receiver
Reduce Gain on mixer / amplifier
Ensure that XLR output is not fed to a Line input
Microphone output is very low
Turn up GAIN ADJUST on beltpack transmitter
Turn up VOLUME on receiver
Increase Gain on mixer / amplifier
Ensure that Jack output is not fed to a Mic input
Ensure that Sensitivity switch is not set to Instrument level
Check transmitter batteries
1622
Errors and omissions excepted.
Copyright© 2012. AVSL Group Ltd.
