14
TABLE 2-5. ENVIRONMENTAL DATA
ITEM DATA
Operating Temperature -40 to +50 °C
Storage Temperature -50 to +70 °C
Humidity 95%, 25°C to 40°C for 48 hr
Illumination Required Natural night illumination
(overcast starlight to moonlight)
Environmental Rating Waterproof
MIL-STD-810 Complies
TABLE 2-6. IR850 SPECIFICATIONS
ITEM DATA
IR Emitter Type LED
Radiated Power 150mW
Peak Wavelength 850nm
Divergence 6 to 20°
Battery Single CR123А (3V)
Battery Life at 20°C 1.5 hr
Overall Dimensions (with Mount, L×W×H) (121Ч41Ч37) mm
Weight (with Mount, without Battery) 0.08 kg
Operating Temperature -30 to +50 °С
Storage Temperature -30 to +50 °С
Environmental Rating Waterproof
2.3 STANDARD COMPONENTS
Nyx-7 standard components are listed in Table 2-7 and shown in Figure 2-2.
FIGURE 2-2. NYX-7 STANDARD COMPONENTS
1
2
3
4 5
6
7
