Table of Contents
1 Introduction
Congratulations you have purchased the most advanced portable gas analyzer
available. The AII-4001 provides unmatched sophisticated performance in a
simple to use package, and, provides users with significant advantages:
Precisely analyze dive gas mixes in any environment without charts. Proprietary
algorithms* and sensors provide extremely accurate one touch calibration.
Note: Failure to account for environmental factors can produce up to 6.7%
error.
Oxygen is compensated for temperature, barometric pressure and RH.
Helium is zeroed when the oxygen is calibrated with air or 100% oxygen.
Algorithms* compensate the Helium value for differences in the thermal con-
ductivity of Oxygen and Nitrogen enabling the AII-4001 to precisely measure
any combination of Helium, Oxygen and Nitrogen.
The large backlit LCD is easily read even in low light condition and provides
additional information to the user:
Temperature, barometric pressure and RH values of the sample gas.
For added safety, the Maximum Operating Depth (MOD) PO2 @ 1.4 ATA of
the gas mix being sampled
Imperial or Metric units at a touch
Rechargeable battery powers the AII-4001 for 16 hours of continuous use.
9 VDC power adapter 110/220 VAC is included, charges battery in 2 hours
The adapter can safely remain connected for bench top operation
Optional 9 VDC cigarette lighter adapter is available
Automatically conserves and protects battery life.
The backlight turns off after 30 seconds and
The AII-4001 completely powers itself off after 15 minutes of non-use
The automatic turn-off features are disabled when externally powered
The analyzer turns off 2-3 hours after the LOW BATTERY warning is displayed
to prevent complete discharge and permanent damage to the battery
The AII-4001 and accessories are packaged in a rugged waterproof plastic enclosure de-
signed specifically for hostile diving conditions. The unmistakable bright red color stands
out in the shop, on the boat or in the water.
* Patent pending
1.1 Contents
Open the red case containing the AII-4001 and confirm you have received the
standard accessories and any optional equipment ordered:
1) AII-4001 Helium Oxygen Trimix Analyzer
2) Flow Manifold (A-3582)
3) Adapter, Dome to 1/8” Tube (A-3609)
4) Tubing, 1/8” x 3 ft. (TUBE-1018)
5) Adapter, 9 VDC 110/220 VAC (PWRS-1003-1)
6) Owner’s Manual
2
1 Introduction 1
2 Quality Control Certification 3
3 General Care & Safety 5
4 Specifications 6
5 Operation 7
5.1 Controls 7
5.2 Power 8
5.3 O 2 Calibration & He Zero 9
5.4 Analysis 10
6 Maintenance 11
7 Replacement Parts & Accessories 12
8 Troubleshooting 13
9 Warranty 14
10 MSDS & Disposal 15
