2 Quality Control Certification


Date:

Customer: Order No.:

Pass

Model:

( ) GPR-18MS Explosion Proof ppm O2 Analyzer S/N ______________________

( ) GPR-18 Explosion Proof ppm O2 Analyzer S/N ______________________

( ) GPR-28 Explosion Proof O2 Analyzer S/N ______________________

Sensor:

( ) GPR-12-2000MS ppm Oxygen Sensor S/N ______________________

( ) GPR or ( ) XLT-12-333 ppm Oxygen Sensor S/N ______________________

( ) GPR-11-32 or ( ) XLT-11-24 Oxygen Sensor S/N ______________________

Approvals:

EN 61326 Minimum Immunity Test
EN 61010-1:2001 Low Voltage Directive

Accessories:

Owner’s Manual

5/16 Open end wrench

Configuration:

A-1107-M PCB Assembly Main / Display

A-1106-M PCB Assembly Power / Relay

Range: ( ) GPR-18MS 0-1 ppm, 0-10 ppm, 0-100 ppm, 0-1000 ppm
( ) GPR-18 0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-25% (air calibration only)
( ) GPR-28 0-1%, 0-5%, 0-10%, 0-25%

Wetted parts: stainless steel ( ) Manual flow and bypass valves, flow indicator
( ) Manual flow meter (with integral metering valve)

Standard power: ( ) 100/110 VAC or ( ) 220/240 VAC

Heater system: ( ) 100/110 VAC or ( ) 220/240 VAC; controller set at 85° F

Test – Electronics: LED indicators: range, alarms

4-20mA offset

Alarm relays activate/deactivate with changes in O

2

concentration

Analog signal output 0-1V and 4-20mA

Range ID contacts (optional)

Test – Gas:

Baseline drift on zero gas <

± 2% F.S. over 24 hour period

Noise level <

± 1.0% F.S.

Span adjustment within 10-50% F.S.

Peak to peak over / under shoot < 0.5% F.S.

Final:

Overall inspection for physical defects; place SAMPLE/BYPASS valve in BYPASS position

Options:

Notes:
