Advanced Instruments Inc.
16
Mounting the Analyzer
The oxygen analyzer consists of two PCB assemblies, sensor housing and sample system valves. An optional temperature
controlled heater system enhances stability during low ppm measurements. In standard configuration the alarm controls are
integral to prevent tampering, however, as illustrated below the alarm controls can be accessed externally with approved
actuators.
These components are packaged in a compact 8” x 8” x 8” wall mount enclosure. Designed for mounting on a flat vertical
surface approximately 5 feet above the floor by bolting the mounting feet attached to the rear of the enclosure. The user is
responsible for selecting the appropriate bolts to support at least 80 pounds.
