2 Quality Control Certification
Date: Customer: Order No.: Pass
Model: GPR-1900 ppm Oxygen Analyzer S/N _____________________
Sensor: ( ) GPR-12-333 ppm Oxygen Sensor
( ) XLT-12-333 ppm Oxygen Sensor S/N _____________________
Accessories: Owner’s Manual
CABL-1008 Power Cord
Configuration: Ranges: 0-10 ppm, 0-100 ppm, 0-1000 ppm, 0-1%, 0-25%
A-1161-1 PCB Assembly Micro / Display – Software V. ______
A-1162 PCB Assembly Power Supply / Interconnection
Power: ( ) 100/120/220/250 VAC
( ) 9-28 VDC non-loop
(GPR-1900R)
(GPR-1900W) Enclosure: ( ) Panel mount 7W x 4”H x 4”D (panel cutout 6”W x 3”H)
( ) Panel mounted with rear cover for 19” rack 19x7x12”
( ) Door mounted for NEMA4 wall mount 12x12x8”
SS sensor housing and 1/8” compression type fittings for inlet and vent
Test System start-up diagnostics satisfactory
Auto/manual range
Alarm relays activate/deactivate with changes in O
2
concentration
Alarm bypass
Analog outputs: 4-20mA signal output
4-20mA range ID reflects range changes
Recovery from air to < 10 ppm in < 60 minutes
Baseline drift on zero gas < ± 2% FS over 24 hour period
Noise level < ± 1.0% FS
Span adjustment within 10-50% FS
Peak to peak over/under shoot < 0.5% FS
Overall inspection for physical defects
Options
Notes
