ARNOTT COIL SPRING CONVERSION KIT
FOR
1999-2006
MERCEDES-BENZ S-CLASS (W220 CHASSIS)
3.
DISCONNECT THE AIRLINE AND REMOVE THE 3 MOUNTING NUTS FROM THE TOP OF THE AIR SHOCK. (FIGURE 20-2)
4.
REMOVE RUBBER BOOT AND DISCONNECT ELECTRICAL CONNECTOR LEADING TO THE SHOCK DAMPER
SOLENOID. (FIGURE 20-3).
5.
REMOVE THE BREAK CALIPER RETAINING CLIP. (FIGURE 20-4)
FIGURE 20-2
FIGURE 20-4
FIGURE 20-3
