Air Suspension C-2675 REV 1 User Manual
Page 4
4
REV 1
12/09/2013
C-2675
C
-2675
aRnott REaR Coil spRing ConVERsion kit
FoR
2003-2009
MERCEDEs-BEnZ E-Class wagon w/o aDs
FigUre 10-5
8.
Dislocate tHe air spring’s top MoUnt FroM tHe veHicle. (FigUre 10-6)
9.
loosen anD reMove tHe air spring’s loWer MoUnting nUt anD bolt. (FigUre 10-7)
7.
loosen anD reMove tHe rear control arM nUt anD bolt. (FigUre 10-5)
FigUre 10-7
FigUre 10-6
