Air Suspension A-2123 REV 4 User Manual
Page 8
8
A-
2123
ARNOTT FRONT AIR SPRING
FOR
2003-2009
LAND ROVER RANGE ROVER
A-2123
REV 4
01/17/2014
7.
AIR SPRING AS WELL AS ALL O-RINGS AND O-RING SPACERS ARE DISCARDED. THE ONLY THING YOU WILL
REUSE IS THE SHOCK ITSELF DISASSEMBLED VIEW OF SHOCK. (FIGURE Q)
8.
CLEAN THE SHOCK OF ANY DEBRIS BEFORE BEGINNING INSTALLATION OF THE AIR SPRING. (FIGURE R)
9.
REMOVAL COMPLETE.
FIGURE Q
FIGURE R
