Air Suspension C-2745 REV 1 User Manual
Page 7
7
REV 1
06/06/2014
C-2745
C-
2745
ARNOTT COil spRiNg CONVERsiON kiT
FOR
2007-2009
JAgUAR XJ sERiEs
REAR coIL sPRING INstALLAtIoN
1.
INSTALLATION IS IN REVERSE ORdER OF AIR STRUT REmOVAL.
Tighten all nuts and bolts to manufacturer's specifications during the installation process.
8.
REmOVE AIR STRUT. (FIGURE 20-7)
FIGURE 20-7
