ASUS MEZ User’s Manual 15
III. HARDWARE SETUP
III. H/W SETUP
Motherboard Settings
DIP Switches (DIP)
Some of the motherboard’s onboard functions can be adjusted through the DIP
switches. The white block represents the switch’s position. The example below shows
all the switches in the OFF position.
MEZ DIP Switches
ON 123456789
1
0
01 01 01
DIP
OFF ON
2. Onboard Audio Setting (DIP-Switch 5)
The onboard audio can be turned ON or OFF using this switch.
MEZ Audio Setting
ON 1234
5
6789
1
0
Disable
ON 1234
5
6789
1
0
Enable
01 01 01
3. VIO Setting (DIP-Switch 6)
The onboard voltage regulator allows you to select the voltage supplied to the
DRAM, chipset, AGP, and the CPU’s I/O buffer.
IMPORTANT! Setting this
function switch to ON (3.66Volt) may reduce system life. It is strongly recom-
mended that you leave this switch on its default setting of OFF (3.50Volt).
ON 12345
6
789
1
0
ON 12345
6
789
1
0
MEZ VIO Setting
3.50Volt 3.66Volt
01 01 01
