ASUS P5Q3 Deluxe/WiFi-AP@n

1-5

ASUS 16-Phase Power Design
The breakthrough technology of 16-phase VRM design is bringing to the

ASUS motherboards. 16-phase power design can reach the power efficiency

up to 96%

+

, and dispel heat generated by VRM module effectively, and lower

temperature 36°C

+

compared to other VRM solution. With all Japanese-made

best quality power components such as low RDS (on) MOSFETs, Ferrite

core chokes with lower hysteresis loss, and high quality conductive polymer

capacitors, ASUS 16-phase VRM design also ensure longer component life,

minimum power loss, and help to reach the superior overclocking score ever

than before.

AI Nap
With AI Nap, the system can continue running at minimum power and noise

when you are temporarily away. To wake the system and return to the OS

environment, simply click the mouse or press a key.

ASUS Quiet Thermal Solution

ASUS Quiet Thermal solution makes system more stable and enhances the

overclocking capability.

Fanless Design - Stack Cool 2
ASUS Stack Cool 2 is a fan-less and zero-noise cooling solution that lowers

the temperature of critical heat generating components. The motherboard

uses a special design on the printed circuit board (PCB) to dissipate heat

these critical components generate.

Fanless Design - Pure Copper Heat-pipe
The Heat Pipe design effectively directs the heat generated by the chipsets to

the heatsink near the back IO ports, where it can be carried away by existing

airflow from CPU fan or bundled optional fan. The purpose of the innovative

heat pipe design on this motherboard is that the groundbreaking fanless

design does not have lifetime problems as a chipset fan does. Furthermore, it

provides options for users to install side-flow fan or passive cooler. The Heat

Pipe design is the most reliable fanless thermal solution to date.

DO NOT uninstall the heat-pipe by yourself. Doing so may bend the tubing and

affect the heat dissipation performance.

For optimal cooling performance, remove the protect film attached on the

ICH10R southbridge before use.
