Chapter 2 – Asus P8Z68-V User Manual
Page 21
ASUS P8Z68-V
2-3
Chapter 2
Layout contents
Connectors/Jumpers/Slots
Page
1.
CPU, chassis, and power fan connectors (4-pin CPU_FAN
/CPU_FAN_OPT, 4-pin CHA_FAN1, 3-pin CHA_FAN2,
3-pin PWR_FAN1-2)
2-26
2.
ATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
2-28
3.
LGA1155 CPU socket
2-4
4.
DDR3 DIMM slots
2-5
5.
TPU switch
2-16
6.
EPU switch
2-17
7.
MemOK! switch
2-15
8.
USB 3.0 connector (20-1 pin USB3_34)
2-23
9.
Intel
®
Z68 Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_1/2 [gray])
2-21
10.
Intel
®
Z68 Serial ATA 3.0 Gb/s connectors
(7-pin SATA3G_3–6 [blue])
2-22
11.
Clear RTC RAM (3-pin CLRTC)
2-20
12.
System panel connector (20-8 pin PANEL)
2-29
13.
USB 2.0 connectors (10-1 pin USB78, USB910, USB1112)
2-24
14.
POWER-on switch
2-14
15.
Front panel audio connector (10-1 pin AAFP)
2-27
16.
Digital audio connector (4-1 pin SPDIF_OUT)
2-25
