5-30

Chapter 5: BIOS setup

5.4.4

Onboard Devices Configuration

Serial Port1 Address

[3F8/IRQ4]

Serial Port1 Mode

[Normal]

Parallel Port Address

[378]

Parallel Port Mode

[Normal]

Serial Port1 Address [3F8/IRQ4]

Allows you to select the Serial Port1 base address.

Configuration options: [Disabled] [3F8/IRQ4][2F8/IRQ3] [3E8/IRQ4] [2E8/IRQ3]

Serial Port1 Mode [Normal]

Allows you to select mode for Serial Port1. Configuration options: [Normal]

[IrDA] [ASK IR]

Parallel Port Address [378]

Allows you to select the Parallel Port base addresses.

Configuration options: [Disabled] [378] [278] [3BC]

Parallel Port Mode [Normal]

Allows you to select the Parallel Port mode. Configuration options: [Normal] [EPP]

[ECP] [EPP+ECP]

Allows BIOS to select

Serial Port1 Base

Address.
