ASUS RS700-E7/RS8 4-3
Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-4
2. VGA controller setting (3-pin VGA_SW1) 4-5
3. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-5
4. RAID configuration utility selection (3-pin RAID_SEL1) 4-6
5. ME firmware force recovery setting (3-pin ME_RCVR1) 4-6
6. Baseboard Management Controller (BMC) Setting (3-pin
BMC_EN1)
4-7
Internal LEDs Page
1. Standby power LED 4-14
2. CPU warning LED (ERR_CPU1, ERR_CPU2) 4-14
3. DIMM warning LED (ERR_DIMMA1-3, ERR_DIMMB1-3,
ERR_DIMMC1-3, ERR_DIMMD1-4, ERR_DIMME1-3,
ERR_DIMMF1-3, ERR_DIMMG1-3, ERR_DIMMH1-3)
4-15
4. BMC LED (BMC_LED) 4-15
Internal connectors Page
1. Serial ATA connectors (7-pin SATA1–2 [blue]) 4-8
2. ISAS1 and ISATA1 connectors 4-8
3. PSAS 1 and 2 connectors 4-9
4. Hard disk activity LED connector (4-pin HDLED1) 4-9
5. USB connectors (10-1 pin USB34, USB56) 4-10
6. Serial port connectors (10-1 pin COM1) 4-10
7. System fan connectors (4-pin FAN1/2/3/4/5/6/7/8) 4-11
8. TPM connector (20-1 pin TPM) 4-11
9. System panel connector (20-pin PANEL1 [white]) 4-12
10. Auxiliary panel connector (20-2 pin AUX_PANEL1) 4-13
