viii
CPU LGA1156 socket for Intel ® Core™ i7/ Core™ i5 processors
Supports Intel ® 45nm Multi-Core CPU
Chipset Intel ® H55 Express Chipset
Memory 4 x DIMM, max. 16GB, DDR3 1333/1066 MHz, non-ECC,
un-buffered memory
Dual channel memory architecture
* When you install a total memory of 4GB capacity or more,
Windows ® 32-bit operating system may only recognize less
than 3GB. We recommend a maximum of 3GB system
memory if you are using a Windows ® 32-bit OS.
** Refer to www.asus.com for the latest Memory QVL
(Qualified Vendors List).
Expansion Slots 1 x PCIe 2.0 x16 slot
1 x PCIe 2.0 x1 slot
2 x PCI slots
Graphics Integrated Intel ® Graphics Media Accelerator (Intel ® GMA4500)
support:
- D-SUB Max. resolution: 2048 x 1536 @75Hz
- DVI Max. resolution: 1920 x 1200 @60Hz
- HDMI Max. resolution: 1920 x 1200 @60Hz
Supports Microsoft ® DirectX 10
Storage Intel ® H55 Express Chipset:
- 6 x Serial ATA 3.0 Gb/s connectors
- 1 x Ultra DMA 133/100 connector
LAN RTL8112L Gigabit LAN controller
Audio VIA VT1708S 8-channel High Definition Audio CODEC
Supports Jack-Detection, Multi-streaming, and Anti-pop
function
USB Supports up to 12 USB 2.0 ports (6 ports at mid-board,
6 ports at the back panel)
ASUS Unique
Features
ASUS EZ Flash 2
ASUS Q-Fan2
ASUS MyLogo 2
ASUS CrashFree BIOS3
ASUS Anti Surge
P7H55-M SI specifications summary
(continued on the next page)
