ASUS M4A785D-M PRO 2-11
Hyper Transport Configuration
HT Link Frequency [Auto]
Allows you to set the HyperTransport link frequency. Configuration options: [Auto] [200 MHz]
[400 MHz] [600 MHz] [800 MHz] [1 GMHz] [1.2 GMHz] [1.4 GMHz] [1.6 GMHz] [1.8 GMHz]
[2.0 GMHz] [2.1 GMHz] [2.4 GMHz] [2.6 GMHz]
HT Link Width [Auto]
Allows you to set the HyperTransport link width. Configuration options: [Auto] [8 But] [16 Bit]
HT Over Voltage
Allows you to set the HyperTransport over voltage or set it to [Auto] for safe mode. Press
<+>/<-> to adjust the value. The value ranges from 1.25000V to 1.38500V.
Memory Timming and Voltage
Memory Clock Mode [Auto]
Allows you to set the memory clock mode. Configuration options: [Auto] [Manual]
The following item appears only when the Memory Clock Mode item is set to [Manual].
Memclock Value [200 MHz]
Allows you to set the memory clock value.
Configuration options: [200 MHz] [266 MHz] [333 MHz] [400 MHz] [533 MHz]
DRAM Timing Mode [Auto]
Allows you to set the DRAM timing mode. Configuration options: [Auto] [DCT 0] [DCT-1]
[Both]
The following sub-items appear only when you set the DRAM Timing Mode item to [Both],
[DCT 0], or [DCT 1].
TCL [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK] [7 CLK DH_Only]
TRCD [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK]
TRP [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK]
tRTP [Auto]
Configuration options: [Auto] [2-4 CLK] [3-5 CLK]
TRAS [Auto]
Configuration options: [Auto] [5 CLK] [6 CLK] ~ [17 CLK] [18 CLK]
TRC [Auto]
Configuration options: [Auto] [11 CLK] [12 CLK] [13 CLK] ~ [23 CLK] [24 CLK] [25 CLK]
tWR [Auto]
Configuration options: [Auto] [3 CLK] [4 CLK] [5 CLK] [6 CLK]
TRRD [Auto]
Configuration options: [Auto] [2 CLK] [3 CLK] [4 CLK] [5 CLK]
tWTR [Auto]
Configuration options: [Auto] [1 CLK] [2 CLK] [3 CLK] [Auto] [1 CLK] [2 CLK] [3 CLK]
