1-6 Chapter 1: Product introduction
1.4 Motherboard overview
Before you install the P4B533-V motherboard, familiarize yourself with its
physical configuration and available features to facilitate the motherboard
installation and future upgrades. A sufficient knowledge of the motherboard
specifications will also help you avoid mistakes that may damage the
board and its components.
1.4.1 Major components
The following are the major components of the P4B533-V motherboard as
pointed out in the picture on page 1-7.
1. DIP switches (DSW1)
2. ATX 12V connector
3. CPU socket
4. North Bridge controller
5. DDR DIMM sockets
6. ASUS EZ Plug™ 12V connector
7. ATX power connector
8. Floppy disk connector
9. IDE connectors
10. South Bridge controller
11. Super I/O controller
12. Standby power LED
13. DIP switches (DSW2)
14. Flash ROM
15. ASUS ASIC
16. Audio controller (optional)
17. PCI slots
18 AGP warning LED
19. AGP slot
20. LAN PHY (optional)
21. PS/2 mouse port
22. Parallel port
23. RJ-45 port (optional)
24. Line In jack (optional)
25. Line Out jack (optional)
26. Microphone jack (optional)
27. USB 2.0 ports 1 and 2
28. Video port
29. Serial port
30. USB 2.0 ports 3 and 4
31. Keyboard port
See page 1-8 for the specifications of each component. Refer to
Chapter 2 for detailed information on the components.
