ASUS RS500A-X6/PS4 5-21
SouthBridge Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
SouthBridge Chipset Configuration
SP5100 CIMx Version : 5.7.0
SB Debug Configuration
OHCI HC (Bus 0 Dev 18 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 18 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 18 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 0) [Enabled]
OHCI HC (Bus 0 Dev 19 Fn 1) [Enabled]
EHCI HC (Bus 0 Dev 19 Fn 2) [Enabled]
OHCI HC (Bus 0 Dev 20 Fn 5) [Enabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Options for SB
Debug Features
SB Debug Configuration
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
SouthBridge Debug Configuration
Advanced
A15 ECOs [Disabled]
Port 0 ESP [ISP]
Port 1 ESP [ISP]
Port 2 ESP [ISP]
Port 3 ESP [ISP]
Port 4 ESP [ISP]
Port 5 ESP [ISP]
Dis #THRMTRIP Before KBRst [Enabled]
SATA-IDE Ports Auto Clk Ctrl [Disabled]
SATA-AHCI Ports Auto Clk Ctrl [Disabled]
SATA PORT0 MODE [Auto]
SATA PORT1 MODE [Auto]
SATA PORT2 MODE [Auto]
SATA PORT3 MODE [Auto]
SATA PORT4 MODE [Auto]
SATA PORT5 MODE [Auto]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Options
Disabled
Enabled
A15 ECOs [Disabled]
Configuration options: [Disabled] [Enabled]
Port 0—5 ESP [ISP]
Allows you to decide the ESP help. Configuration options: [ISP] [ESP]
Dis #THRMTRIP Before KBRst [Enabled]
Configuration options: [Disabled] [Enabled]
SATA-IDE Ports Auto Clk Ctrl [Disabled]
When set to [Enabled], the clocks for unused SATA ports in IDE will be shut
down and the system saves some power.
Configuration options: [Disabled] [Enabled]
