Layout contents
Jumpers
Page
1.
Clear RTC RAM (CLRTC1)
4-4
2.
VGA controller setting (3-pin VGA_SW1))
4-5
3.
DDR3 voltage control setting
(4-pin LVDDR3_SEL1; LVDDR3_SEL2)
4-6
4.
LAN controller setting (3-pin LAN_SW1, LAN_SW2)
4-6
5.
CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
4-5
6.
Force BIOS recovery setting (3-pin RECOVERY1)
4-7
Internal connectors
Page
1.
Serial ATA connectors
(7-pin SATA1, SATA2, SATA3, SATA4; RED)
(7-pin SATA5, SATA6; Black)
4-8
2.
SAS connectors
(7-pin SAS1, SAS2, SAS3, SAS4; Red)
(7-pin SAS5, SAS6, SAS7, SAS8; Blue)
4-9
3.
USB connector (10-1 pin USB34, USB56; A-Type USB8)
4-9
4.
CPU, front and rear fan connectors
(4-pin CPU_FAN1/2; REAR_FAN1/2; FRNT_FAN1—4)
4-10
5.
Serial General Purpose Input/Output connectors
(8-1 pin SGPIO1/2)
4-11
6.
Serial General Purpose Input/Output connectors
(8-1 pin SGPIO3/4)
4-11
7.
BMC header (BMC_FW1)
4-12
8.
Thermal sensor cable connectors (3-pin TR1, TR2)
4-10
9.
SSI power connectors
(24-pin ATXPWR1, 8-pin ATX12V1, 8-pin ATX12V2)
4-13
10.
Power Supply SMBus connector (5-pin PSUSMB1)
4-12
11.
Location LED cable connector (3-pin LOCLED1)
4-13
12.
System panel connector (20-pin PANEL1)
4-14
13.
Auxiliary panel connector (20-2 pin AUX_PANEL1)
4-15
