5.4.2 Chipset Configuration
The Chipset configuration menu allows you to change advanced chipset settings.
Select an item then press to display the submenu.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
Advanced Chipset Settings
NorthBridge Configuration
SouthBridge Configuration
SR5650 Configuration
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Options for NB
NorthBridge Configuration
v02.61 (C)Copyright 1985-2008, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
CPU Bridge Chipset Configuration
CPU REVISION :B0
Current CSI Frequency :6.400GT
Current Memory Frequency :1066 Mhz
CSI Links Speed [Full-Speed]
CSI Frequency [Auto]
Memory Frequency [Auto]
Memory Mode [Independent]
Demand Scrubbing [Disabled]
Patrol Scrubbing [Disabled]
Throttling - Closed Loop [Disabled]
Throttling - Open Loop [Disabled]
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
To transition the CSI
links to full-speed
or leave them in
slow-mode.
v02.61 (C)Copyright 1985-2010, American Megatrends, Inc.
BIOS SETUP UTILITY
Advanced
NorthBridge Chipset Configuration
Memory Configuration
ECC Configuration
DRAM Timing Configuration
Memory CLK :667 MHz, N/A
CAS Latency(Tcl) :9 CLK , N/A
RAS/CAS Delay(Trcd) :9 CLK , N/A
Row Precharge Time(Trp) :9 CLK , N/A
Min Active RAS(Tras) :24 CLK , N/A
RAS/RAS Delay(Trrd) :4 CLK , N/A
Row Cycle(Trc) :33 CLK , N/A
Read to Precharge(Trtp) :5 CLK , N/A
Write Recover Time(Twr) :10 CLK , N/A
←→ Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
