ASUS RS500A-X6/PS4
1-3
1.3
System specifications
The ASUS RS500A-X6/PS4 is a server featuring the ASUS KCNR-D12 server
board. The server supports AMD
®
LGA 1207 Opteron™ 4100 series processors
with HyperTransport™ technology, plus other latest technologies through the
chipsets onboard.
(continued on the next page)
Processor Support / System Bus
2 x Socket C32 (LGA 1207)
4/6 Core AMD
®
Opteron™ 4100 Series
HyperTransport™ Technology 3.0,
6.4 GT/s per link (dual link)
Core Logic
AMD
®
SR5650
AMD
®
SP5100
Memory
Total Slots
12 (2-channel per CPU)
Capacity
Maximum up to 128GB (RDIMM)
Maximum up to 32GB (UDIMM)
Memory Type
DDR3 800/1066/1333 UDIMM with ECC / non ECC
DDR3 800/1066/1333 RDIMM
Memory Size
1GB, 2GB, 4GB, 8GB (RDIMM)
1GB, 2GB, 4GB (UDIMM)
Expansion Slots
Total PCI-E Slots
1
Slot Type
Default Riser Card:
1 x PCI-E x16 slot (x8 link) (Full-Height/Half-Length)
1 x PCI-E x8 slot (x8 link) (Full-Height/Half-Length)
Additional Slot
1 x PIKE Slot for Storage Enhancement
Storage
SATA Controller
AMD
®
SP5100:
6 x SATA2 300MB/s ports
PROMISE
®
SW RAID (For Linux/Windows)
Supports software RAID 0, 1, 10 & 5
* A RAID array over 2TB can be set as a data disk
only.
SAS Controller
Optional:
ASUS PIKE 1064E 4-port SAS RAID card
ASUS PIKE 1078 8-port SAS HW RAID card
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card
with RAID 5
HDD Bays
I = Internal
A or S will be
hot-swappable
4 x Hot-Swap 3.5” SAS/SATA2 HDD Bays
Networking
LAN
2 x Intel 82574L
1 x Mgmt LAN
Graphic
VGA
Aspeed AST2050 8MB
